Version Page Draw Changes
2011 V1
2012 V1 7 Added warning 'Interference between carrier and tilt module at the lowest seat height'
Deleted Sedeo Lite and Pro part. Became a seperated manual.
12 01 Added article numbers 1007080, 9006237, 00000.4042 and 00000.4035 (position 14a - 14d, socket
head screws)
13 02 Added article numbers 9002784, 9006360 and 9006452 (position 32, 37 and 38)
14 03 Added article numbers 9006781 till 9006790 Motor 4-pole Alpine
14 03 Added article numbers 9002784, 9006361 and 9005107 (position 39, 44a and 44b)
15 04 Changed article number 9005987 castor wheels outdoor into right version and added 9006820 left
version
2012 V2 96 7.2 Changed minimum seat width 420 mm into 400 mm and added specifi cations turning radius and for
Puma 40 changed minimum seat depth from 420 into 440 mm
83-94 6 Replaced left / right indications by m1 or m2. Side is depending from FWD or RWD.
2012 v3 7 2.3 Changed text 'interference between carrier and tilt module at the lowest seat height' into 'interference
precautions'
79 Added text with notice by ´Adjusting the centre point of gravity´ instruction
82 Deleted notice text with 'Adjusting the mechanical seat tilt' instruction
83 Added 'Adjusting the electrical seat tilt 0 - 25°' instruction
84-89 Added 5.2.6 'Seat tilt confi guration tables'
2013 v1 13 1 • Added article number 9002752 Set battery connection covers
14 2 • Deleted position 22. Added symbol C with position 23: fasten with locktite 270
• Changed description of article number 9005940, 9005941, 9005942 and 9005943
• Changed article numbers and description of position 28-32,35a/35b/36a/36b,37,38: 9005944 into
9007485, 9005945 into 9007486, 9005946 into 9007488 and 9005947 into 9007489
• Changed QTY of position 37 article number 9006360 from 2 into 1
15 3 • Deleted article numbers 9005949, 9005948, 9005951, 9005950, 9005952, 9005953, 9005954
and 9005955
• Changed description and position numbers of 4 pole motors
• Deleted position 44a: article number 9006361 and changed position 44b into 44
20 8 • Changed article number 9006199 into 9006023
• Added article number 9007749
21 9 • Changed position numbers of article number 9006020, 9006019 and 9006021
• Added article number 9007749
2013 v2 10 3.1 Added locktite 270 to tools table
14 2 Changed article numbers of position 28-32,33a/33b/34a/34b,37,38: 9005940 into 9007479, 9005941
into 9007480, 9005942 into 9007482 and 9005943 into 9007483
16 4 • Added article numbers 9007752,9007753 and 9007754 (Castor fork 60 mm and castor wheels
200x50)
• Changed quantity article numbers 9005987 and 9006820 from 2 into 1
• Added article number 9006792 (position 13-15)
17 5 • Changed quantity article numbers 9006000, 9005999, 9006005, 9006004, 9006002, 9006001,
9006007 and 9006006 from 2 into 1
• Added article number 9006008 (position 17-21)
21 9 Added article numbers 9007683 and 9007684
22 10 • Changed drawing fi xed kerb climber into adjustable kerb climber
• Changed articel number 9005740 into 9007864
• Changed article number 9003520 into 03411.0190
23 4.5 Changed article number position 8; 9006030 into 9006031
25 4.4 • Added article number 9007158 (position 4b)
• Deleted article numbers 9006434 and 9002481 (position 9 and 10) and added article numbers
9002480 and 1010114 (position 9 and 10)
• Added article number 9006229 (position 23)
• Added article number 9003607 (position 24)
27 4.4 Added Flowchart R-net system upward of mid-October 2012
28 4.5 • Changed description article numbers 9006028 and 9006032 (ACU3 into ACU1)
• Changed position 7 in 7a and added position 7b: 9007620
• Added article numbers 00355.0013, 9006970, 9007576, 9007581, 9007621 and 9007619
(position 17, 28, 29, 30 and 31)
• Changed description and article numbers of position 16, 20, 21 and 22
30 4.5 Added Flowchart DX2 system upward of mid-October 2012
31 4.6 Added article number 1010114 (position 24)
34 5.2.1 Added 'Replacing Puma 20 motors'
42 Deleted article numbers 9006434 and 9002481
