Loctite 243
Torx 30
7Nm
Lubricant
Caution! Apply Loctite 243 to the bolt of the castor fork!
Note! Tighten the bolt of the castor fork with 7 Nm!
9
Note! Tighten the shaft and nut of the castor wheels with 25 Nm!
Caution! Place at the Puma 20 on both sides of the castor
wheel an extra ring between the wheel and the fork!
10
