OPER
ATING MANUAL FOR SELECT ANALYST
Issue: A, part number R041118
29
9 INSTALLATION KIT
Your installation kit comprises the following items.
Contents:
3 metres ½” Blue hose,
7metres 8mm nylon tubing,.
1 off Jubilee clip.
3 metres ,12mm nylon tubing,.
1 off 12mm stem elbow.
3 off 8mm stem elbows.
9.1 Media cartridge packs
Your Select Analyst is supplied with two different media cartridge packs
which are available in two sizes depending on your unit capacity.
A media preteatment pack and a Puripac polishing cartridge. Size 8 for
unit types 40,80,160 and size 16 for unit type 320.
The Select Analyst must be fitted with a media pre-treatment pack
PT8/PT16 and a Puripac PP8 /PP16.
The pretreatment pack must be fitted in the left hand position and the
Puripac cartridge in the right hand position when viewed from the front.
Refer to Section 6.4, Maintenance and service spares, for re-ordering
details.
