ATING MANUAL FOR SELECT ANALYST
Issue: A, part number R041118
30
9.2 Feed water supply requirements
The unit has been designed to operate only on potable tap water and
should comply with the following limits.
Feed water supply requirements
Free Chlorine < 1 ppm as Cl
2
Total dissolved solids (max) 1000 ppm
Temperature 1-35
o
C (33.8 – 95
o
F)
Feed water pressure (max) 90 psi
Feed water pressure (min) 30 psi*
Optimum pressure 60 psi
* If your feedwater pressure is below this minimum value the performance
of the unit will be affected
Contact your water supplier if outside these limits.
9.3 Electrical supply
Your Select Anaylst will require a single phase electrical supply that meets
the requirements below
Electrical
Supply
KW
Rating
Current
Draw (Amps)
External Fuse
Rating
Single phase
100-240v +
10%,
50 Hz and Earth
0.1 1.0 5 Amps
(conforming to
BS1362)
Ensure that the mains supply is provided via a convenient switched outlet
and is protected with a 5 amp fuse.
9.4 Unit positioning
The Select Analyst has been designed to be bench or wall mounted.
9.4.1 Bench mounted
Locate the unit on a suitable work surface, ensuring access to tank
dispense bib tap and sufficient clearance to rear of the machine for all
water and electrical connections.
All water feed connections are found on the rear of the unit. Using the
installation kit provided attach the water feed, drain and overflow tubing
as shown below.
