Purite Select Analyst - Drain Connection; Installation of Media Cartridge Packs

OPER
ATING MANUAL FOR SELECT ANALYST
Issue: A, part number R041118
32
9.5 Drain connection
Attach a suitable length of 8mm tubing to the drain connection so that the
free end may be inserted into an appropriate drain. The tubing must not be
kinked or the flow restricted in anyway.
If the drain is to be run over 5 meters and/or rises above the level of the
unit then contact our Service Department for advice.
Attach a suitable length 12mm hose to the overflow connection on the unit
and run to a suitable drain point. If the drain is to be run over 5 meters
and/or rises above the level of the unit then contact our Services Dept for
advice.
9.6 Installation of media cartridge packs
Remove the door of the unit by tugging gently on the hand hold provided in
the door.
Remove the cartridge media packs from their
packaging and remove the black protective caps
from the inlet and outlet ports.
Insert the Pretreatment (PT8 or PT16) in the left hand retaining block
pushing it home until it clicks into position and retaining mechanism clicks
up.
Insert the Puripac PP8 or PP16 pack in the right hand retaining block
pushing it home until it clicks into position and retaining mechanism clicks
up.
 Replace the door by locating the top of the door under the retaining
mouldings and lifting the bottom of the door until it slides home.
 Switch on water supply to the unit.
 Switch on the electrical supply to the unit.
 This touch screen display will illuminate and display the start screen.
