can connect to the WAN host through the internal IP.
Figure 19. IP mapping
Specific steps:
1> Connect the device to the LAN port of AC200/1000,
2> Parameters of the IP mapping is listed in the following table,
Table 5.
Items
Description
Device IP
The IP of the device connected to the LAN port.
Mapping IP
WAN IP of AC200/1000
Host IP
The IP of the device connected to the WAN port.
Internal IP
Should be in the same segment of the device IP.
3> Set the IP of PC to the same network segment as the mapped WAN port IP and connect to the WAN port of
AC200/1000. Hardware connection is like the following:
