Pylontech Force-L2

12 / 31
2
---
---
---
3
---
---
TX
4
CANH
---
---
5
CANL
---
---
6
GND
RX
7
---
RS485A
---
8
---
RS485B
---
Note: Other Pin must be NULL, if not may influence the communication of system.
2.3 System Diagram
