Pyronix EURO 46 V10 Installation Manual

5
EURO 46 V10 Installation Manual
Input Mapping
Devices Address Input Numbers
EURO 46 V10 PCB N/A 1-8
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU /EURO-ZEM32-WE 0 9-16
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU /EURO-ZEM32-WE 1 17-24
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU /EURO-ZEM32-WE 2 25-32
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU /EURO-ZEM32-WE 3 33-40
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU /EURO-ZEM32-WE 4 41-48
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU /EURO-ZEM32-WE 5 49-56
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU /EURO-ZEM32-WE 6 57-64
EURO-ZEM8 / EURO-ZEM8+/ EURO-ZEM8+PSU /EURO-ZEM32-WE 7 65-72
EURO-LCD/EX 0 73-74
EURO-LCD/EX / EURO-PROX/INT 1 75-76
TOTAL 76
PLEASE NOTE: 2 x EURO-ZEM32-WE can be connected to the EURO 46 V10. Each expander
allows 32 inputs which are separated into 4 addresses (each address enables 8 wireless inputs). It is
possible to mix the wired and wireless remote expanders.
PLEASE NOTE: If the EURO-PROX/INT (Internal Tag Reader) is programmed as a ‘Set Point’ device,
2 inputs are enabled. If the EURO-PROX/INT is programmed as ‘Entry Control’ or ‘Access Control’
only 1 input is enabled.
