Technical Specification
Programming Outputs Power Rating Normal State Active State
PGM 1 Relay, 3A, max 30V Changeover NC & NO Changeover NC & NO
Speaker 16 ohms No tones
Repeat RKP tones & internal
sounder
Strobe output 500mA 12v 0v
Bell output 500mA 12v 0v
XPGM 1 (Input 7) 50mA Floating 0v
XPGM 2 (Input 8) 50mA Floating 0v
ATE outputs 2mA 5v 0v
Circuit States
Resistance Range
1k / 1k Range 4k7 / 2k2 Range 4k7 / 4k7 Range
Normal 0k5 to 1k4 1k4 to 2k9 3k7 to 8k3
Alarm 1k5 to 5k9 4k2 to 7k8 8k4 to 10k2
Fault 6k to 8k1 8k to 11k3 10k3 to 14k9
Masking 8k2 to 17k 11k6 to 22k 15k to 22k
Tamper <0k5 or >17k <1k4 or >22k <3k7 or >22k
Fuses Value Type
Bell fuse for bell terminals F800mA quick blow 250V Glass
Aux fuse for aux terminals F800mA quick blow 250V Glass
RS485 bus fuse for bus terminals F800mA quick blow 250V Glass
Battery fuse for battery terminals
T 1.5A anti-surge slow blow
250V
Glass
230V mains fuse for mains terminals
T500mA H anti-surge slow
blow 250V
Ceramic
Panel Power Supply Output Nominal Range
Output voltage ~13.7VDC ~10-15VDC
Output current
Small Metal 1A Continuous
1.5A peak, during battery
charging
Large Metal 1.5A Continuous
2.0A peak, during battery
charging
Panel Power Supply Input Nominal Range
Mains supply voltage AC 230 VAC at 50Hz -15% +10 %
Transformer rating
Small metal 18VA 18V at 1.0A
Large metal 45VA 18.5V at 2.5A
Power Supply Type A.
Maximum output peak voltage: Max 100 mV
SD Voltage which the deep discharge protection function will operate at: 10V
Over Voltage Protection Trigger Voltage: 18V
Battery Charging Specification
Float voltage 13.8VDC Recharge time <24 hours
Battery low voltage cut off 10.5V
Standby battery capacity
current
300mA (3A to 6A)
700mA (7A to 17A)
To Next Page
