EURO 46 V10 Installation Manual
PLEASE NOTE: EURO 46 V10 power supplies are NOT designed for use with multiple batteries
connected. System load should not exceed the panel power supply output shown above, or the
maximum load supportable by the battery for the specified backup time, as in the table shown below.
The power ratings are based on battery shown in table – but battery capable of supporting the
system load for the required time may be used without affecting these ratings.
EN50131-6:2008 Rated Output
In accordance with EN50131-6:2008, the EURO standby times and effective output currents depend on the Security Grade of the
system and how 230V mains missing fault is signalled to the Alarm Receiving Centre. Power supplies are rated in accordance with
the requirements of EN50131-6, which are related to the maximum battery size that can be accommodated in the housing and vary
according to the grade of the system in which they are installed, as per the following table:
Electrical Capability EN50131-6 Rating. Maximum Load
Example Battery Model Grade 2 Grade 3
Yuasa NP7-12 0.5A 0.3A
Yuasa NP17-12 1.2A 0.7A
EURO 46 V10 PCB Current Consumption Environmental
Quiescent 80mA Operational -10°C to +40°C, Certified
User Code and Tag Guessing
Storage -20°C to +60°C
4-digit codes 10,000 Humidity 75%
6-digit codes 100,000
Dimensions
Disallowed codes None
Metal case
Small case
250 x 297 x 82mm
Weight: 4.8kg inc. battery
All codes 1612 Large case
390 x 305 x 100mm
Weight: 11.5kg inc. battery
According to EN50131-3:2009 Annex B PCB 170 x 90 x 30mm
According to spec of manufacturer of RFID components used EN50131 Grading 3
The below table specifies ATS (Alarm Transmission System) performance criteria in accordance with
the requirements of EN50136-1.
Notification Equipment
Grade 2 Criteria Grade 3 Criteria
Options Options
A B C D A B C D
Remotely powered external sounder 2
Optional Optional Optional
2
Optional Optional Optional
Self-powered external sounder
Optional
1
Optional Optional Optional
1
Optional Optional
Main communication path (ATS) ATS 2 ATS 2 ATS 2 ATS 3 ATS 4 ATS 4 ATS 4 ATS 5
Second communication path (ATS)
Optional Optional
ATS 1
Optional Optional Optional
ATS 3
Optional
