6.2.1 Voting Mode
Settings Description
Voting N
umber:
For a given list of sensors assigned to a relay actuation list, this
number indicates the minimum number of sensors which must
pass or equal their alarm “On” concentration before the relay will
actuate
Default is 1
Assign Sensor:
Each relay may be assigned to any one or more of the enabled
sensors or AI (Analog Inputs)
On
Concentration
Reading:
Off Concentration
Reading:
If On Concentration is great than or equal to Off Concentration:
On Concentration: For each sensor or analog input assigned, set
the concentration at or above which the voting number will
increase 1
Off Concentration: For each sensor or analog input assigned, set
the concentration at or below which the voting number will
decrease 1
On
Con
ce
ntration
Reading:
Off Concentration
Reading:
If On Concentration is less than Off Concentration:
On Concentration: For each sensor or analog input assigned, set
the concentration below which the voting number will increase 1
Off Concentration: For each sensor or analog input assigned, set
the concentration above which the voting number will decrease 1
