6.12 Menu “Assign Output”
Each output can be assigned their own inputs with the alarm settings associated with the
input as applied to the output only.
Settings Description
Sele
ct Channel
:
Available outputs:
 Relay1 to Relay3
 M-Relay 0 to 11
 AO CH1 to CH8
 Buzzer and Strobe
Ass
ig
n
ed In
put
:
Available inputs:
 Digital Sensor 0 to Sensor 31
 AI CH1 to CH8
On C
oncentration
:
When the sensor is assigned to a Relay or Buzzer/Strobe
 When the relay is working with voting mode, the
sensor’s On Concentration is needed. See relay
configuration in 6.2.1
 When the relay is working with averaging mode,
the sensor’s On Concentration is not needed.
O
ff
C
oncentration
:
See above, only for relay/buzzer/strobe voting mode
Reading at
4mA
:
When a sensor is assigned to an Analog Output
 When the AO is calculated with “Base AI mA
Value”, the digital sensor’s concentration needs to
convert to mA value, this is the concentration at 4mA
output
 When the AO is calculated with “Base
Concentration”, the value is not needed.
Reading at
20mA
:
See above, only for AO with “Base AI mA Value”
