Qel M-CONTROLLER II - Menu Ai Setting; Menu Bi Setting

M-Controller II System Operation Manual - 23 -
84350-201-001 Rev C
6.6 Menu “AI Setting”
For Analog Input Channel 1 to Channel 8 configuration
Settings Description
Enable
:
The Controller must be told which channels are active
Gas Type
:
Set the gas type for the display only.
Gas
Unit
:
Set the units of measurement for the display only
Reading at
4mA
:
Reading at 20mA:
Assign the two readings at 4.0 milliamps and 20.0 milliamps input
signal. You may even assign a gas concentration to 4.0mA, which
is higher than the concentration assigned to 20.0mA. The M-
Controller will draw a straight line between.
6.7 Menu “BI Setting”
For Switch / Binary Input Channel 1 and Channel 2 configuration
Settings Description
Enable
:
The Controller must be told which channels are active
W
ork Style
:
_
Acuate Outputs:

When the BI is ON, the assigned output will be overridden to
ON state. The Switch can be used to manually actuate
assigned outputs
_
Hush Buzzer and Relay:

When the BI is ON, all alarmed buzzers and buzzer style
relays will be Hushed
_
Clear Latched Relay:

When the BI is ON, all latched relays will be clear and reset.
The switch needs to press again to switch OFF manually
when it’s shown “Expired”
Assigned Output
:
Available outputs:

Relay1- Relay3, Buzzer1 – Buzzer 3, Strobe

Enabled M-Relay, M-Annunciator and QRP

Enabled AO-Board (AO-1 to AO-8)
