Qel M-CONTROLLER II - Menu Sensor Setting

M-Controller II System Operation Manual - 22 -
84350-201-001 Rev C
Show BO Na
me
:
If the parameter is OFF: all relays output will be displayed and
named with “R-XX”, such as R04 to R99 to represent relay4 to
relay99
If the parameter is ON: all relays output will be display with MR-
XX-YY, or MA-XX-YY, or QRP-XX-YY.
MR means M-Relay, MA means M-Annunciator
XX is the device box address, YY is the channel number 1 up to 8
Default is ON
CAL AO
-
B
oard 4mA
:
For factory calibration. Do not attempt to modify these settings
in the field
CAL
AO
-
Boa
rd 20mA
:
For factory calibration. Do not attempt to modify these settings
in the field
Q
C CAL AI 4
-
20
mA
:
For factory calibration. Do not attempt to modify these settings
in the field
QC CAL AO
-
Board
:
For factory calibration. Do not attempt to modify these settings
in the field
6.5 Menu “Sensor Setting”
For digital sensor 0 to sensor 31 configuration
To assign a sensor or analog input to any of the output devices (relays, buzzers, and AO
Board) the sensor must already have been enabled in the sensor settings.
Only the enabled sensors will be polled and monitored by the controller. The sensor’s gas
type and measurement unit will be read out of each enabled sensor.
Settings Description
Enable
:
The M-Controller must be told that a sensor is attached to the
control system
