M-Controller II System Operation Manual - 25 -
84350-201-001 Rev C
6.10 Menu “AO Setting”
For option daughter board AO-Board CH1 to CH8 configuration
Details see AO Board Operation Manual (84350-212-000)
Settings Description
Sele
ct Channel
:
AO-1 to AO-8
E
nable
:
The Controller must be told which channels are active
Work
Style
:
_Base Concentration
_Base AI mA Value
Work
M
ode:
AO output calculation work mode:
_Averaging Mode
_Peak Mode
Reading at 4m
A
:
Reading at 20mA:
Assign a value (which can be a concentration or mA value
depends on the work style of the channel) for both the 4.0mA
signal, and the 20mA signal. You may assign a larger value for 4.0
milliamps than for 20 milliamps; the M-Controller will still stretch
a straight-line signal between the two points.
6.11 Menu “Buzzer / Strobe”
Settings Description
Enable
:
The Controller must be told which channels are active
Voting Mod
e
:
See relay configuration in 6.2
Averaging Mode:
See relay configuration in 6.2
On Delay
(Minutes):
See relay configuration in 6.2
Off Delay
(
Minute
s):
See relay configuration in 6.2
Fault Ac
turation:
See relay configuration in 6.2
