6.2.2 Averaging Mode
When working in Averaging mode, the Voting mode is disabled, and the Voting Number
is forbidden automatically. Input values to “Average On”, “Average Off”.
If Average On is great than or equal to Average Off:
Settings Description
Average On
:
The gas concentration at or above which the average of all the
sensors assigned to this relay will cause the relay to actuate
Average
Off
:
The gas concentration at or below which the average of all the
sensors assigned to this relay will cause the relay to de-actuate
If Average On is less than Average Off:
Settings Description
Average
O
n
:
The gas concentration at or below which the average of all the
sensors assigned to this relay will cause the relay to actuate
Average
Off
:
The gas concentration at or above which the average of all the
sensors assigned to this relay will cause the relay to de-actuate
