6.4 Menu “System Setting”
The Menu system setup contains general settings for monitor operations, communications
and 4-20mA calibrations.
Settings Description
Backlight:
Can be set to “Always ON”, “Always OFF”, “AUTO”
Default setting is AUTO mode
C
AL AI 4
mA
:
For factory calibration. Do not attempt to modify these settings
in the field
C
AL AI
20
mA
:
For factory calibration. Do not attempt to modify these settings
in the field
Modbus
Address
:
The slave device address in Modbus RTU protocol
Default is 3
M
odbus B
aud
R
ate
:
Baud rate for Modbus port
Default is 19200bps
Mod
bus Parity:
Parity bit for Modbus port
Default is no parity
Change Password
:
The new password can be any combination of up to four digits
Default password is 4321
Key Beeper
:
Beeping or not when the keypad is pressed
Default is ON
Stro
be Out
:
When the strobe is actuated, it can be set with either 100% duty
cycle ON or 50% duty cycle ON, so the strobe can be flashed by
the strobe relay ON and OFF at 50% duty cycle
Default is 100% duty ON
M
-
Relay:
M-Annunciator:
QRP:
Show how many M-Relay, M-Annunciator and QPR installed in
the system
You can define each device address here
