Qel M-CONTROLLER II - Menu Relay 1 - 3; Menu M-Relay

M-Controller II System Operation Manual - 24 -
84350-201-001 Rev C
6.8 Menu “Relay 1 - 3”
For on-board Relay1 to Relay3 configuration
Settings Description
Enable
:
The Controller must be told which relays are active
Work style
:
Normal Relay Style or Buzzer Relay Style
Normally Energiz
e
d
Normally De-Energized or Normally Energized
Latched
See relay configuration in 6.2
Voting Mod
e
:
See relay configuration in 6.2
Averaging Mode:
See relay configuration in 6.2
On Delay
(Minutes):
See relay configuration in 6.2
Of
f Delay
(Minute
s
)
:
See relay configuration in 6.2
Fault Ac
turation:
See relay configuration in 6.2
6.9 Menu “M-Relay”
Select enabled M-Relay, set address and each channel relay configuration
Settings Description
Device
from
Address 0 to
Address 11:
Available devices:
 M-Relay
 M-Annunciator
 QRP
 Not Install
Select Cha
n
n
el
Select the channel of enabled device
Relay
Setting
Set the channel relay configuration
See relay configuration in 6.2
