4 – Managing Switches
Switch Data Window
4-4 59235-02 A
L
Fan 2 Status Fan 2 status
Fan 3 Status Fan 3 Status
Power Supply 1 Status Power supply 1 status
Power Supply 2 Status Power supply 2 status
Temperature Failure Port
Shutdown
Non-configurable (always enabled for this switch). All
ports are downed when the switch temperature exceeds
the Failure Temperature.
Warning Temperature Non-configurable temperature threshold (65° Celsius)
above which a warning condition alarm is generated.
Failure Temperature Non-configurable temperature threshold (70° Celsius)
above which a failure condition alarm is generated.
Diag Status The current diagnostic state of switch.
Diag Fault Code The code value for the last recorded diagnostic test result
recorded on the switch.
Test Status The current diagnostic test status of switch.
Test Fault Code The code value for the last recorded diagnostic test status
recorded on the switch.
Network Group
IP Address Internet Protocol address
Subnet Mask Mask that determines the IP address subnet
Gateway Gateway address
SNMP Enabled SNMP enabled or disabled.
Broadcast Support Broadcast support status. Broadcast support is enabled
(default) or disabled.
NTP Client Enabled Enabled or disabled. Allows for switches to synchronize
their time to a centralized server.
NTP Server Address The IP address of the centralized NTP server. Ethernet
connection to NTP server is required.
Use Front Port Use this option to activate the two CPU Ethernet connec-
tions on the backplate, or activate the two Maintenance
Panel Ethernet connections on the faceplate (SB9000
Series switches only).
Table 4-1. Switch Data Window Entries (Continued)
Entry Description
