10. Remove the rear panel.
a. Remove the screws securing the rear panel to the chassis.
Note
• The at head M3x4 screws require a Phillips #2 screwdriver.
• To prevent misalignment or stress on the cover during removal, remove the
screws in the following order: top edge rst, then sides, back panel, and bottom
last.
11. Remove the fan cables.
a. Remove the fan cables from the backplane tray.
| NAS Repair Manual
Category C NAS Models 67
