Terminal connection
Cable type 1 2 3 4 5 6 7 8 Notes
Belden 8723 2 Pair red black white nc nc green nc nc
As used in many DT
installations
Belden 8777 3 Pair
red
(pr1)
black
(pr1)
white
(pr2)
nc nc
black
(pr2)
nc nc
General purpose
cable suitable for DT
3M Cable red black white nc nc blue nc nc
Specialised cable
designed for DT
Cat 5 Cable
white/
orange
orange
white/
green
nc nc green nc nc Cat 5 Cable
All Cat5 cables terminated during an installation must be tested before use.
