Quail Digital Pro9 - Pro9 System Components

page 29
Pro9 system components
Pro9 Headset - Q-P9HS
Operating frequency
1.88-1.90GHz EMEA, Asia
1.91-1.93GHz North America
Power
250mw EMEA, Asia
125mw North America
Pro9 Base Station - Q-P9BS
Operating frequency
1.88-1.90GHz EMEA, Asia
1.91-1.93GHz North America
Power
250mw EMEA, Asia
125mw North America
Pro9 Base PSU Q-P9BS PSU
100-240v AC voltage sensing
48v DC 1.25 amp output
Pro9 Speaker & enclosure
Q-P9SPK
Mylar waterproof cone, enclosure
IP64 15watts /30 peak, 8 ohms
210 to 7000 Hz
4 pin GX16 connector
117x117x73mm without bracket
682g
Pro9 Charger - Q-P9CH
8 port
Power light
Individual battery status lights
205x325x45mm
710g
Pro9 Charger PSU Q-PSU12
100-240v AC voltage sensing
12v DC 5 amp output
IEC mains lead supplied
Pro9 Drive-thru Module
Q-P9DTM
Process and digitizes clean audio
from speaker and microphone to
and from order taker.
Vehicle loop detector (inc) or sonar
252x170x55mm without
connectors - 880g
Pro9 Microphone & enclosure
Q-P9MIC
Mylar waterproof cone, enclosure
IP64, 50 ohms
210 to 7000 Hz
3 pin GX16 connector
117x117x73mm without bracket
682g
