QUANTA QuantaGrid Series User Manual

ABOUT THE SYSTEM INTRODUCTION
1-2
Processor
Processor type:
Intel
® Xeon® processor E5-2600 v3 product family
Max. TDP support:
 135W
Number of processors: 2
Internal Interconnect: 6.4 / 8.0 / 9.6 GT/s
L3 Cache : Up to 45 MB
Chipset
Intel
® C610
Memory
Total slots: 8
Capacity: Up to 256GB RDIMM / Up to 512GB LRDIMM
Memory type: 2133 MHz DDR4 RDIMM / LRDIMM
Memory size: 32GB, 16GB, 8GB RDIMM / 64GB, 32GB LRDIMM
Storage controller
Onboard (Intel® C610):
 10x SATA 6Gb/s ports
 SATA RAID 0, 1, 10
Optional controller:
 Quanta LSI® 2308 6Gb/s SAS mezzanine, RAID 0, 1, 10
 Quanta LSI® 3008 12Gb/s SAS mezzanine, RAID 0, 1, 10
 Quanta LSI® 2208 6Gb/s RAID mezzanine, RAID 0, 1, 5, 10 (RAID 6 with
additional RAID key)
Networking
LOM:
Option 1
 Intel® I210 dual-port 1 GbE, Dedicated 1 GbE management port
Option 2
 Intel® I210 dual-port 1 GbE + Intel® I350 dual-port 1 GbE,
Dedicated 1 GbE management port
Optional NIC: (more options refer to the CCL))
 Quanta Intel® I350 dual-port OCP mezzanine
 Quanta Intel® X540 dual-port 10GbE BASE-T OCP mezzanine
 Quanta Intel® 82599ES dual-port 10G SFP+ OCP mezzanine
Expansion slots
Option 1 (default)
 One x8 PCIe 3.0 SAS mezzanine slot
 One x8 PCIe 3.0 LP MD-2
 One x8 PCIe 3.0 OCP LAN mezzanine slot
Option 2
 One x8 PCIe 3.0 Quanta LAN mezzanine slot
 One x8 PCIe 3.0 LP MD-2
 One x8 PCIe 3.0 OCP LAN mezzanine slot
Storage
Option 1 (default)
 10x 2.5" hot-plug
Option 2
 4x 3.5" hot-plug , 2x 2.5" fixed SSD
Onboard storage
 2x SATADOM (optional)
 1x M.2 SSD (PCIe x4, Dimension: 22mm x 60mm, 22mm x 80mm)
Table 1.1: System Specifications (Continued)
