BMC FRU INFORMATION
3-24
View this Event Log
View the Event Log page for the selected sensor.
Sensor Reading status
You can read currently sensor status in this page, each sensor name have its SDR setting
data in BMC function SPEC, the status according SDR setting will display as following
matrix:
Event Log
In MegaRAC GUI, this page displays the list of event logs occurred by the different sensors
on this device. Double click on a record to see the details of that entry. You can use the
sensor type or sensor name filter options to view those specific events or you can also sort
the list of entries by clicking on any of the column headers.
To open the Event Log page, click Server Health > Event Log from the top menu. A sam-
ple screenshot of the Event Log page is shown as follows.
Figure 3-14. Event Log Page
The Event Log page consists of the following fields.
Table 8: Sensor Readings status
STATUS CURRENT READING
N/A N/A
All deasserted 0x80xx(*2)
Normal Value with unit
Event string(*1)
(*1) Please refer IPMI2.0 standard specification chapter 42.
(*2) Please refer IPMI2.0 standard specification chapter 42 and SDR setting in BMC function specification.
