690 Appendix B Image Reference
SlideX
Description This image displays a black background with a large white vertical bar moving across the
screen.
After pressing the Step key, the speed of vertical bar movement can be increased by
turning the Image knob (turn clockwise to speed up image).
To change the animation speed using the command-line interface:
1. Establish a terminal session with the generator (see page 14).
2. Load the SlideX image.
3. Enter the following commands:
ISUB 1
IVER 1
IMGU
DELX 10;
IMGU
DELX 20;IMGU
SMPTE133
Description This image is based on a recommended practice (RP-133) test pattern designed by the
Society of Motion Picture and Television Engineers (SMPTE). The original application was
used in testing and evaluating medical imaging monochrome displays. The image now is
