Quantum DXi6900

Chapter 9: Configuration
VTL Configuration
Quantum DXi6900 User’s Guide 228
LibraryModel Select the library model emulated by the partition. The library model determines the
inquiry string returned to the host by the DXi6900.
The following library models are available:
Models
l Quantum DXi7500
l ADIC Pathlight VX
l Quantum Scalar i40/i80 or Quantum Scalar i6000
l Quantum DXi6700, Quantum DXi6900, Quantum DXi6800, Quantum DXi4700,
Quantum DXi4601, Quantum DXi4500, or Quantum DXi8500
l Quantum DX3000 or Quantum DX5000
l Quantum PX500 or Quantum PX720
l ATL M2500, ATL P1000, or ATL P7000
If you select a library such as the ATL P1000 or ATL P7000, the DXi6900 appears
as the selected library to the host and backup application. If you select Quantum
DXi6900, the host and backup application recognize the device as a Quantum
DXi6900.
Note:Quantum recommends that you set the library model to Quantum
DXi6900 for best compatibility. If your backup application does not support the
Quantum DXi6900 inquiry string, select a different library model. Check your
software compatibility guide to verify what library models are supported.
NumberofStorage
Slots
Enter the number of storage slots in the partition (up to 9,000).
Note:One I/E slot is created for each storage slot up to a maximum of 240 I/E
slots.
NumberofVirtual
TapeDrives
Enter the number of virtual tape drives in the partition.
Note:If all tape drives are currently assigned to other partitions, you must
remove one or more tape drives from an existing partition to make them
available for use in a new partition.
4. (Optional) Under ReplicationSettings, specify replication settings.
For more information about configuring replication for a partition, or to set up replication for the partition
at a later time, see Replication on page 130.
5. Click Apply.
6. Click Online to return the partition to an online state.
