Quantum DXi6900

Chapter 11: System Specifications
DXi6900 Physical Characteristics
Quantum DXi6900 User’s Guide 390
AverageACCurrent Node 586 Watts, 5.9A @100 VAC 2100 BTU/hr
586 Watts, 2.3A @240 VAC 2100 BTU/hr
Array Module (RBOD) 334 Watts, 3.3A @100 VAC 1140 BTU/hr 334
Watts, 1.4A @240 VAC 1140 BTU/hr
Expansion Module (EBOD) 228 Watts, 2.3A @100 VAC 780 BTU/hr
228 Watts, 1.0A @240 VAC 780 BTU/hr
InrushPeakACCurrent Maximum Configuration 81A @ 100 VAC 34A @ 240 VAC
DXi6900 G2 Power Requirements
DXi6900G2PowerRequirements
PowerSuppliesand
Cords
Node
Expansion Module (RBOD)
Two (2) hot-swappable redundant power supplies
Two (2) USA type 3-prong power cords with
IEC320C13to Nema5-15 connectors:
Two (2) C13 to C14 type 3-prong power cords with
IEC320C13to IEC320C14 connectors:
