Chapter 1 Specifications
4
Models QT-740 & QT-750 - Service Manual
ELECTRICAL SPECIFICATIONS
Input Power: 115 VAC (±10%), 15 Amps, 50/60 Hz
230 VAC (±10%), 10 Amps, 50/60 Hz
Mode of Operation:
Model QT-740: Continuous
Model QT-750: Intermittent Operation (80 cycles/hour max.)
Momentary Current:
Model QT-740: 2.0 Amps
Model QT-750: 5.0 Amps
Long Term Current:
Model QT-740: 0.05 Amps
Model QT-750: 0.20 Amps
Locking System Power: 24 VDC/4.35 Amp
SYSTEM OPTIONS
• Abdominal compression band
• Lateral cassette holder (for cross-table work)
SYSTEM OPERATING ENVIRONMENT
Ambient Temperature: +10°C to +40°C
Relative Humidity: 20 to 80%, non-condensing
Altitude: -30.5 to +2440 meters relative to sea level
NON-OPERATING ENVIRONMENT
Ambient Temperature: -18°C to +70°C
Relative Humidity: 20 to 95%, non-condensing
Altitude: -30.5 to +3048 meters relative to sea level
