Chapter 4 Service Instructions
46
Models QT-740 & QT-750 - Service Manual
ORDERING INFORMATION
To order replacement parts for the tubestand, contact the Service Department at;
Quantum Medical Imaging, LLC.
2905 Veterans Memorial Highway
Ronkonkoma, New York 11779 USA
Phone: (631) 587-5800
When ordering replacement parts, supply the following information:
•Model and serial number of equipment
•Part number
•Part description
•Quantity required
When ordering components or parts not listed in Table 2, a complete description
of the part, including its function and location should be provided with the
model number and serial number of the unit.
10 Switch, FLOAT Push But-
ton
EL50-002 QT-750
QT-740
1
1
11 AC Transformer EL55-008 QT-750 1
12 DC Motor Driver Board EL67-002 QT-750 1
13 DC Motor EL66-001 QT-750 1
14 Line Filter EL99-001 QT-750 1
15 Fuse, 6 Amp (115 VAC
Input)
Fuse, 3 Amp (230 VAC
Input)
EL45-006
EL45-009
QT-750 1
16 Brake, Fail-Safe, Lead
Screw
EL80-002 QT-750 2
17 Brake, Fail-Safe, DC Motor EL80-001 QT-750 1
18 Belt, Drive ME46-004 QT-750 1
19 Belt, Sync ME46-005 QT-750 1
Item Description
Part
Number
Model(s)
Used On
Qty Used
in System
