Chapter 1 Specifications
Models QT-740 & QT-750 - Service Manual
3
PHYSICAL SPECIFICATIONS
The following are physical specifications of the radiographic tables:
TABLETOP SPECIFICATIONS
Length: 85.0 inches (2159.0 mm)
Width: 35.5 inches (901.7 mm)
Height (Model QT-740): 32.5 inches (825.5 mm)
Height (Model QT-750):
Raised: 32.5 inches (825.5 mm)
Lowered: 21.0 inches (533.4 mm)
Tabletop Travel:
Longitudinal: 32 inches (812.8 mm)
Lateral: 10 inches (254 mm)
Tabletop Motion: 4-Way Floating
Tabletop Material: Fiber-resin (phenolic)
Tabletop X-ray Density: <1.0 mm Aluminum
Tabletop-to-Film Plane
Distance: approx. 2.5 inches (63.5 mm)
TABLE BASE SPECIFICATIONS
Width: 48.0 inches (1219.2 mm)
Depth: 26.0 inches (660.4 mm)
Weight Capacity (Max. Patient
Load): 650 lbs. (295 kg)
IMAGE RECEPTOR SPECIFICATIONS
Compatible With: Grid Cabinet, Bucky, ACL Bucky
Receptor Longitudinal Travel: 20.0 inches (508.0 mm)
SYSTEM SPECIFICATIONS
Tube Stand Compatibility: Compatible with all Quantum Medical Imaging
tube stands and overhead tube cranes
Overall Weight:
Model QT-740: 350.0 lbs. (158.8 kg)
Model QT-750: 500.0 lbs. (226.8 kg)
