Chapter 2 Assembly & Installation
Models QT-740 & QT-750 - Service Manual
11
.
POWER INPUT
CABLE
TERMINAL
BOARD TB2
TERMINAL
BOARD TB1
Figure 3. Connecting Input Power Cable
Figure 4. System Ground Wire Connections
