Chapter 2: Description
Control Module
12 Scalar i6000 Planning Guide
Control modules in dual-robotics libraries can take advantage of two
columns of storage (up to 14 additional magazines) that are unavailable
in single-robotics configurations.
Figure 5 shows where the additional
magazines are located.
Figure 5 Additional Storage
Available in Dual-Robotics
Control Modules
Note: Extra magazine slots are only available if the drive slots are not
in use.
Control module
Rack 1 (rear wall)
Control module
Rack 2 (door)
