GV200 User Manual
3.2.3. GSM antenna specification
Table 5: GSM antenna specification
GSM antenna specification
Frequency and bandwidth GSM850: 824MHz to 894MHz
EGSM900: 880MHz to 960MHz
DCS1800: 1710MHz to 1885MHz
PCS1900: 1850MHz to 1990MHz
Direction: Omnidirection
Gain: Passive: >0dBi
Impedance: 50Ω
VSWR: <4
Efficient: GSM850: >40%
EGSM900: >40%
DCS1800: >30%
PCS1900: >30%
TRACGV200UM001 - 11 -
