GV200 User Manual
0. Revision History
Revision Date Author Description of change
1.00 2011-01-26 Leo LEI Initial
1.01 2011-04-07 Leo LEI 1> add the description of reset key
2> add a controlled function on VOUT
3> modify analog inputs to support more type
sensors
1.02 2011-05-10 Hendry PAN 1> Add the recommendation of microphone in
chapter 3.5
2> Modify the max current of RELAY in chapter
3.3.12
3> Add GSM light mode to indicate that SIM card
inserted into GV200 need pin code to unlock.
1.03 2011-10-21 Leo LEI 1> Change the color of TXD and TXD2 from
Orange to Orange/Gray in Table 7
2> Change the color of DTR from Orange to
Orange/Brown in Table 7.
1.04 2011-12-22 Leo LEI 1> Add the description of a new assembled
harness cable which is named
GV200_RELAY_CABLE in chapter 4.
2> Modify the Figure 11.
3> Modify the description of DIN1 and DIN4 in
chapter 3.3.8.
1.05 2012-07-23 Leo LEI 1> Modify the introduction of chapter 1;
2> Modify the content of figure 9 and figure 16;
3> Add the description of the internal flyback
diode in chapter 3.3.11;
4> Delete the chapter 3.3.12;
5> Modify the description of Ignition control in
chapter 3.3.6;
6> Modify the description of DOUT4 in Table 7;
7> Add Suitable Hardware Version.
