Quectel 5G Series User Manual

5G Module Series
5G EVB User Guide
5G_EVB_User_Guide 9 / 36
2 General Overview
Quectel supplies 5G EVB for engineers to develop applications based on Quectel 5G modules. This EVB
can be used to test basic functionalities of these modules.
2.1. Key Features
The following table describes the detailed features of 5G EVB.
Table 1: Key Features
Features
Implementation
Power Supply
DC power supply: 4.5–5.5 V
Typical: +5 V/ 3 A
Module TE-A Interface
Support Quectel 5G and LTE-A EG512R-EA modules
PHY TE-A Interface
Support PHY AR8035
AP TE-A Interface
Reserved
SD Card Interface
Support SD card
(U)SIM Card Interface
Support dual (U)SIM card: 2.95 V and 1.8 V
Audio Interfaces
⚫ 1 digital audio codec board interface:
Supporting ALC5616-TE-A and TLV320AIC3104-TE-A codec boards
⚫ 2 analog audio interfaces:
Used for loudspeaker and earphone
UART Interface
⚫ COM1: Serial connector J2003 is for data communication.
⚫ COM2: Serial connector J2002 is for debugging.
USB Interface
USB Type C interface
PCIe to USB Interface
Reserved
Signal Indication
5 LEDs are available for signal indication
Button and Switches
⚫ PWRKEY (S0202)
