Table 24: Module Current Consumption (3.3V VBAT Power Supply)
Power OFF (AT+QPOWD=0)
AP Mode
Modem Mode
Min.
Typ.
Max.
2)
Unit
/
/
2.7
µA
Deep Sleep
AP Mode
Modem Mode
Min.
Typ.
Max.
2)
Unit
Idle
PSM
3.5
μA
Light Sleep
AP Mode
Modem Mode
Min.
Typ.
Max.
2)
Unit
Idle
eDRX=81.92s, PTW=40.96s
288
µA
@DRX=1.28s
541
μA
@DRX=2.56s
434
μA
Active
1)
AP Mode
Modem Mode
Min.
Typ.
Max.
2)
Unit
Normal
Single-tone
(15kHz subcarrier
spacing)
B1 @ 23dBm
100
285
mA
B2 @ 23dBm
103
294
mA
B3 @ 23dBm
107
308
mA
B4 @ 23dBm
107
307
mA
B5 @ 23dBm
107
303
mA
B8 @ 23dBm
113
325
mA
B12 @ 23dBm
134
393
mA
B13 @ 23dBm
111
319
mA
B17 @ 23dBm
133
392
mA
B18 @ 23dBm
110
316
mA
B19 @ 23dBm
109
311
mA
