Quectel BC66 - Page 48

NB-IoT Module Series
BC66 Hardware Design
BC66_Hardware_Design 47 / 59
1.
1)
Power consumption under instrument test condition.
2.
2)
The “maximum value” in “Active” mode refers to the maximum pulse current during RF emission.
3. “*” means under development.
B20 @ 23dBm
109
301
mA
B25 @ 23dBm
103
293
mA
B26* @ TBD
TBD
TBD
mA
B28 @ 23dBm
128
375
mA
B66 @ 23dBm
109
312
mA
Single-tone
(3.75kHz subcarrier
spacing)
B1 @ 23dBm
193
302
mA
B2 @ 23dBm
187
296
mA
B3 @ 23dBm
215
335
mA
B4 @ 23dBm
237
311
mA
B5 @ 23dBm
215
330
mA
B8 @ 23dBm
224
344
mA
B12 @ 23dBm
250
395
mA
B13 @ 23dBm
203
316
mA
B17 @ 23dBm
258
409
mA
B18 @ 23dBm
198
313
mA
B19 @ 23dBm
198
314
mA
B20 @ 23dBm
215
329
mA
B25 @ 23dBm
187
297
mA
B26* @ TBD
TBD
TBD
mA
B28 @ 23dBm
250
398
mA
B66 @ 23dBm
200
316
mA
NOTES
