Quectel EC25-AUX

LTE Standard Module Series
EC25 Hardware Design
EC25_Hardware_Design 108 / 130
Table 54: EC25-AUT Conducted RF Receiving Sensitivity
Frequency Primary Diversity SIMO
1)
3GPP (SIMO)
WCDMA B1 -110.0dBm / / -106.7dBm
WCDMA B5 -110.5dBm / / -104.7dBm
LTE-FDD B1 (10MHz) -98.5dBm -98.0dBm -101.0dBm -96.3dBm
LTE-FDD B3 (10MHz) -98.0dBm -97.0dBm -100.0dBm -93.3dBm
LTE-FDD B5 (10MHz) -98.0dBm -99.0dBm -102.5dBm -94.3dBm
LTE-FDD B7 (10MHz) -97.0dBm -97.0dBm -98.5dBm -94.3dBm
LTE-FDD B28 (10MHz) -97.0dBm -99.0dBm -102.0dBm -94.8dBm
Table 55: EC25-AUTL Conducted RF Receiving Sensitivity
Table 56: EC25-AF Conducted RF Receiving Sensitivity
LTE-FDD B8 (10MHz) -99.2dBm -98.2dBm -102.2dBm -93.3dBm
LTE-FDD B28 (10MHz) -98.6dBm -98.7dBm -102.0dBm -94.8dBm
LTE-TDD B40 (10MHz) -97.2dBm -98.4dBm -101.2dBm -96.3dBm
Frequency Primary Diversity SIMO
1)
3GPP (SIMO)
LTE-FDD B3 (10MHz) -98.0dBm -97.0dBm -100.0dBm -93.3dBm
LTE-FDD B7 (10MHz) -97.0dBm -97.0dBm -98.5dBm -94.3dBm
LTE-FDD B28 (10MHz) -97.0dBm -99.0dBm -102.0dBm -94.8dBm
Frequency Primary Diversity SIMO
1)
3GPP (SIMO)
WCDMA B2 -109.5dBm -110dBm -110.4dBm -104.7dBm
WCDMA B4 -109.6dBm -110dBm -110.6dBm -106.7dBm
WCDMA B5 -110dBm -110dBm -110.7dBm -104.7dBm
