Quectel EC25-AUX

LTE Standard Module Series
EC25 Hardware Design
EC25_Hardware_Design 122 / 130
8.3. Packaging
EC25 is packaged in tap and reel carriers. Each reel is 11.88m long and contains 250pcs modules. The
figure below shows the package details, measured in mm.
30.3
±0.15
29.3
±0.15
30.3
±0.15
32.5
±0.15
33.5
±0.15
0.35± 0.05
4.2
±0.15
3.1
±0.15
32.5± 0.15
33.5± 0.15
4.00
±0.1
2.00
±0.1
1.75
±0.1
20.20
±0.15
44.00
±0.3
44.00
±0.1
1
.
5
0
±
0
.
1
Max slope 2~3°C/sec
Reflow time (D: over 220°C) 40~60sec
Max temperature 238~245°C
Cooling down slope 1~4°C/sec
Reflow Cycle
Max reflow cycle 1
