Quectel EC25-AUX

LTE Standard Module Series
EC25 Hardware Design
EC25_Hardware_Design 26 / 130
USB_VBUS 71 PI
USB power supply,
used for USB
detection
Vmax=5.25V
Vmin=3.0V
Vnorm=5.0V
Typical: 5.0V
If unused, keep it
open.
USB_DP 69 IO
USB differential data
bus (+)
Compliant with USB
2.0 standard
specification.
Require differential
impedance of 90Ω.
If unused, keep it
open.
USB_DM 70 IO
USB differential data
bus (-)
Compliant with USB
2.0 standard
specification.
Require differential
impedance of 90Ω.
If unused, keep it
open.
(U)SIM Interface
Pin Name Pin No. I/O Description DC Characteristics Comment
USIM_GND 10
Specified ground for
(U)SIM card
USIM_
PRESENCE
13 DI
(U)SIM card
insertion detection
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
If unused, keep it
open.
USIM_VDD 14 PO
Power supply for
(U)SIM card
For 1.8V(U)SIM:
Vmax=1.9V
Vmin=1.7V
For 3.0V(U)SIM:
Vmax=3.05V
Vmin=2.7V
I
O
max=50mA
Either 1.8V or 3.0V is
supported by the
module automatically.
USIM_DATA 15 IO
Data signal of
(U)SIM card
For 1.8V (U)SIM:
V
IL
max=0.6V
V
IH
min=1.2V
V
OL
max=0.45V
V
OH
min=1.35V
For 3.0V (U)SIM:
V
IL
max=1.0V
V
IH
min=1.95V
V
OL
max=0.45V
V
OH
min=2.55V
USIM_CLK 16 DO
Clock signal of
(U)SIM card
For 1.8V (U)SIM:
V
OL
max=0.45V
V
OH
min=1.35V
