LTE
Module
Series
EC25-V
User
Manual
EC25-V_
User_Manual
Confidentia
l / Released
29
/
69
PWRKEY
S1
Close to S1
TVS
Figure
11
: Turn on the
Module Usi
ng Key
stroke
The turn on s
cenario is
illustrat
ed in the follow
ing figure.
V
IL
≤ 0.5V
V
IH
≥ 1.3V
VBAT
PWRKEY
≥ 100ms
RESET_N
STATUS
(OD)
Inactive
Active
UART
NOTE
Inactive
Active
USB
TBD
TBD
TBD
Figure
12
: Timing of T
urning
on Module
Make sure that VBA
T
is stable before pulling down P
WRKEY
pin. The time between them is
no less than
30ms.
NOTE
29
31
