LTE-A Module Series
EM06 Series Hardware Design
EM06_Series_Hardware_Design 14 / 69
1.
1)
Within operation temperature range, the module is 3GPP compliant.
2.
2)
Within extended temperature range, the module keeps the ability to establish and maintain a voice,
SMS, data transmission, emergency call, etc. There won’t be unrecoverable malfunctions. Nor will
there be effects on the radio spectrum or harm to radio networks. Only one or more parameters like
P
out
might reduce in the value and exceed specified tolerances. When the temperature returns to
normal operation temperature levels, the module will meet 3GPP specifications again.
3. “*” means under development.
- Windows 7/8/8.1/10
- Linux 2.6–5.4
- Android 4.x/5.x/6.x/7.x/8.x/9.x
⚫ Include main antenna, Rx-diversity antenna and GNSS antenna
connectors
⚫ Support LTE/WCDMA Rx-diversity
⚫ Gen8C Lite of Qualcomm
⚫ Protocol: NMEA 0183
⚫ Data rate: 1 Hz
⚫ Compliant with 3GPP TS 27.007, 27.005 and Quectel enhanced AT
commands
⚫ Size: (42.0 ±0.15) mm × (30.0 ±0.15) mm × (2.3 ±0.10) mm
⚫ Weight: approx. 6.5 g
⚫ Operation temperature range: -30 °C to +70 °C
1)
⚫ Extended temperature range: -40 °C to +85 °C
2)
⚫ Storage temperature range: -40 °C to +90 °C
⚫ Through USB 2.0 interface
⚫ DFOTA
All hardware components are fully compliant with EU RoHS directive
