Quectel LC29H Series User Manual

GNSS Module Series
LC29H_Series_EVB_User_Guide 15 / 38
Function
Interfaces
Description
Others
J402
OBD
Used for WHEELTICK and FWD signals
input (only LC29H (BA, CA)). Pins are
detailed in Table 5: J402 Pin Description.
Pin description of J401 is shown below:
Table 4: J401 Pin Description
Test Point
No.
Test Point
Label
Test Point
Function
I/O
Description
1
GND
GND
-
Ground
2
PIN1
U601: Pin 1
DI
WAKEUP: Wakes up the module from
Backup mode
3
PIN2
U601: Pin 2
DI
FWD: Forward/Backward status signal
input (only LC29H (BA, CA))
4
PIN3
U601: Pin 3
DO
1PPS:1 pulse per second
5
PIN4
U601: Pin 4
DI
WHEELTICK: Odometer/Wheel-tick
pulse input (only LC29H (BA, CA))
6
PIN5
U601: Pin 5
DI
D_SEL1: Selects UART1/SPI*/I2C
7
PIN6
U601: Pin 6
DI
D_SEL2: Selects UART1/SPI*/I2C
8
PIN7
U601: Pin 7
PO
VDD_EXT: Provides 2.8 V for external
circuit
9
PIN8
U601: Pin 8
DI
RESET_N: Resets the module
10
PIN9
U601: Pin 9
PO
VDD_RF: Supplies power for external RF
components
11
PIN14
U601: Pin 14
DO
ANT_ON: Control external LNA and
active antenna power
12
PIN15
U601: Pin 15
DO
TXD2: UART2 transmits data
13
PIN16
U601: Pin 16
DI
RXD2: UART2 receives data
14
PIN17
U601: Pin 17
DO
WI*: Warming indicator (only
LC29H (BA, CA))
15
No label
-
-
NC (Not Connected)
16
No label
-
-
NC
17
No label
-
-
NC
