GNSS Module Series
LC29H_Series_EVB_User_Guide 8 / 38
1 Introduction
This document provides information on the steps needed to evaluate the Quectel LC29H series module
by using the Evaluation Board (EVB). The EVB is a convenient tool that allows you to become familiar with
the LC29H series modules.
The Quectel LC29H series module includes five variants: LC29H (AA), LC29H (BA), LC29H (CA),
LC29H (DA) and LC29H (EA).
Specifically, the document is divided into several sections:
⚫ Chapter 2 provides the general overview of EVB kit;
⚫ Chapter 3 describes the EVB interfaces;
⚫ Chapter 4 describes how to test the module and upgrade firmware via QGNSS tool;
⚫ Chapter 5 describes the application of the DR function;
⚫ Chapter 6 describes how to test the RTK function;
⚫ Chapter 7 describes the installation of EVB and antenna.
⚫ Chapter 8 describes how to measure power consumption for the module.
⚫ Chapter 9 provides the EVB framework.
⚫ Chapter 10 describes the common problems and troubleshooting.
⚫ Chapter 11 describes the cautions.
⚫ Chapter 12 is an appendix, which summarizes the relevant documents, terms and abbreviations
appearing herein.
⚫
1. Request QGNSS software tool from Quectel Technical Support (support@quectel.com).
2. For more details on how to use LC29H (BS) EVB, see document [1] EVB user guide.
