UMTS/HSPA/LTE Module Series
UMTS&LTE EVB User Guide
UMTS&LTE_EVB_User_Guide Confidential / Released 9 / 44
2 General Overview
Quectel supplies UMTS&LTE EVB for designers to develop applications based on Quectel UMTS&LTE
modules and Wi-Fi modules. This EVB can test basic functionalities of these modules.
2.1. Applicable Modules
UMTS&LTE EVB is applicable to the following module models.
UC20
UGxx
1)
EC2x
2)
FC20 series
3)
EG95
2.2. Key Features
The following table describes the detailed features of UMTS&LTE EVB.
Table 1: Key Features
Features
Implementation
Power Supply
DC supply: 4.5~5.5V, typically: 5V
VBAT: 3.8V for J103
UMTS&LTE TE-A Interface
Support Quectel UMTS&LTE modules: UC20/UGxx/EC2x/EG95
NOTES
Quectel
Confidential
