4.9. Switches and Buttons
The UMTS<E EVB includes two switches (S201 and S901) and three buttons (S301, S302 and S303),
as shown in the following figures.
Figure 27: S901 Switch
Figure 28: S201 Switch and S301/S302/S303 Buttons
Table 10: Description of Switches and Buttons
Control power supply VBAT ON/OFF
Switched to the left: connect FC20's BT interface (UART, PCM) to EC2x
modules, for testing the BT function of FC20.
Switched to the right: connect the main UART and codec board interfaces
