UMTS/HSPA/LTE Module Series
UMTS&LTE EVB User Guide
UMTS&LTE_EVB_User_Guide Confidential / Released 15 / 44
GNSS Antenna (passive)
1
Wi-Fi Antenna
1
Audio
Earphone
1
Disk
USB 2.0 to RS232 driver and USB driver disk
1
Codec Boards
ALC5616 and TLV320AIC3104 codec boards
2
Others
Bolts and nuts for fixing EVB
1
Instruction Sheet
A sheet of paper giving instructions for EVB
connection, details of EVB accessories, etc.
1
NOTE
