UMTS/HSPA/LTE Module Series
UMTS<E EVB User Guide
UMTS<E_EVB_User_Guide Confidential / Released 36 / 44
Connected directly to I2C_SDA of UMTS<E module
Connected directly to PCM_OUT of UMTS<E module
Connected directly to I2C_SCL of UMTS<E module
Connected directly to PCM_CLK of UMTS<E module
Connected directly to WAKE_IN of UMTS<E module
Connected directly to SPI_CS_N of UMTS<E module
Connected directly to AP_READY of UMTS<E module
Connected directly to SPI_CLK of UMTS<E module
Connected directly to W_DISABLE# of UMTS<E module
Connected directly to SPI_MISO of UMTS<E module
Connected directly to USB_BOOT of UMTS<E module
Connected directly to SPI_MOSI of UMTS<E module
Connected to VDD_1.8V via a resistor
Connected directly to voltage translator
Connected directly to voltage translator
Connected directly to voltage translator
Connected directly to voltage translator
Connected directly to voltage translator
Connected directly to voltage translator
Connected directly to DTR of UMTS<E module
