QUICK-ROTAN MINI-STOP Q41MSII - Page 16

8.1.6 Functional sequence 3 (<799> = 3) without stop after seam end (<603> = II)
For Pegasus EX(T) 5214 ... BT250 with stitch lock at the beginning
Functions: chain vacuuming at start
chain vacuuming at end
thread tension on between start and end
chain-off finger between start and end
Switch condition of the keys at the OC-TOP:
Key T9 (P/M) off (dark)
Key T10 (T/E) off (dark)
Key T6 on (bright)
Key T7 on (bright)
Key T15 on (bright)
Q-41-MSII-2-EN 8.8 02-02-21
Fig. 8.3b
max
hell
Dark
0
0
1
1
0
0
- 2
12 D
Pedal
LS
n
1
0
* Outp. A8
* . A5Outp
* . A6Outp
1
* . A2Outp
0
<216>
* see electrical connections dia
g
ram pa
g
e 12.2
Motor runs
Chain vacuum
Thread tension
Chain-off finge
r
(CD)
S 2
<105> <110>
(AB)
S 1
<105>
ML
KESAU
FSP (<766>)
<541>
<112> <112> <112>
<543> <541>
KEFI (<766>)
<216>
<215>
(AB)
S 1
