8. Application
The MINI-TOP Type Q41MS is specially designed for overlock machines and is mainly conceived for
light-barrier control.
The connection of the light-barrier is possible either via the the external operators control panel OC-TOP
or directly at the socket X5 at the control box (Input E6).
The drive system includes three different functional sequences.
Selection of the functional sequences is made via parameter <799>.
Sewing work can be manual or programmed. Programmed sewing is only possible in conjunction with
the external oparator panel QC-TOP/DQ
Extent and contents of sewing programs
a) Number of sewing programs: 5
b) To each sewing program can be assigned the following functions
function: adjustment via:
rated stitchcount S1.x via keys A+/A-/B+/B-
rated stitchcount S2.x via keys C+/C-/D+/D-
rated stitchcount S3.x via keys L+/L-
chain vacuuming at start via key T6
chain vacuuming at end via key T7
chopper at start via key T11
chopper at end via key T12
presser foot position at sewing stop via key T13
presser foot position at program end via key T14
light-barrier via key T15
c) Sewing speed (rated speed) for seam sections S1.x and S2.x can be selected via keys A+/A-.
d) Sewing speed can be changed over between constant (automatic) and variable (treadle-controlled)
via key T2.
e) There is the possibility of running various sewing programs consecutively. During programming, the
subsequent sewing program is shown in digits 6 and 7 of the display and is entered via keys D+ or
D-.
00 means that only the current program is run. At the end of the program concerned, return is made
to its beginning.
Display showing
- before or after start, when <605> = II,
Setting the rated stitchcount S1 and S2 is posssible only with the machine stopped.
S1 via keys A+/A-/B+/B-
S2 via keys C+/C-/D+/D-
Sewing program (x), being activated
when T9 (P/M) is pressed (bright)
Rated stitchcount (S1) to
vacuuming OFF at start
Rated stitchcount (S2) to
vacuuming OFF at end
1 0 1 0 xx/00
